A free-standing desktop unit that can be used as an access card enrolment reader.
PP1-RXU80The ELITE series RXU is a free-standing desktop unit that can be used as an access card enrolment reader. If required, the reader may be screw fixed to the desktop or a suitable wall surface.
The enrolment reader connects to a PC via a USB port and is configured using the Third Millennium ‘TM Data Entry’ application. This is a system application that runs in the background of a Windows-based iOS.
The reader supports a wide variety of output formats, allowing it to be used in most access control and related applications, e.g. time and attendance, cashless vending, etc.
Voltage: +5Vdc to +16Vdc
Current: 250mA typical
Data Voltage: Rest >4Vdc / Active <1Vdc
Data Output: Wiegand, Clock & Data, Custom Outputs
Indication: 1 RGB LED
Sounder: Integral speaker
Dimensions: 96mm x 52mm x 32mm (3.8 x 2.1 x 1.3 inches)
Housing: Moulded polycarbonate/ABS
Mounting: Free standing (or screw-fixed)
USB: Type A
